304 Sheet Metal Custom Heat Pump Outdoor Neat Sea Air Source Heat Pump 5HP

Basic Information
Place of Origin: China
Brand Name: Meidibao
Certification: CE
Model Number: M-C15AAH-304
Document: Product Brochure PDF
Minimum Order Quantity: 6units
Price: negotiate a price
Packaging Details: Factory standard packing
Delivery Time: Specific to the order based on regular products 5 to 7 days. Custom made for 30 days
Payment Terms: T/T
Supply Ability: 20 units
Detail Information
Name: Custom Heat Pump Material: 304 Sheet Metal
Heat Exchanger: Shell In Coil Working Ambient Temperature: 0~43C
Refrigerant: R410 Power Supply: 1/220V/ 60Hz
Type: Air Source Heat Pump
Highlight:

304 Sheet Metal Custom Heat Pump

,

Custom Heat Pump Outdoor

,

Neat Sea Air Source Heat Pump


Product Description

5HP Custom Heat Pump outdoor , neat sea Air Source water heater



Product Description:

Meidibao air source heat pump system is powered by ambient air and operates around the clock: it provides continuous hot water thrughout the yeat and throughout the year,regardless of weather . The opreating cost is 67% less than that of gas water heater, 75% less than that of electric water heater and 60% less than that of boiler.Intelligent control: The unit is automatically controlled by a microcomputer, and automatically runs according to the water temperature of the water tank and the user's water use, without the need for special duty. Reasonable arrangement of low front



Feature:

1. Easy installation,Monoblock fybe

2. Famous brand compressor

3. EEV

4. Auto protection



Specification:

                                                       15kw Commercial Air Source Heat Pump
Model:   M-C15AAH-304
Climate type:   Normal
Power supply:   220V 1N~/60Hz
Rated heating capacity: kw 15.6
Rated power input: kw 3.41
Rated current: A 15.5
Water heating capacity: L/h 417
Refrigerant/charging volume:   R410a/1600g
Max. exhaust pressure: MPa 3.0MPa
Min. suction pressure: MPa 0.05MPa
Rated hot water temp.: 55℃
Max. hot water temp.: 60℃
Water pipe size:   1.0"
Noise level: dB(A) ≤53dB(A)
Anti-electric shock rate   I
Protection grade:   IP×4
Dimensions: mm 1120*510*1275
Net weight: kg 150kg



Advantages:

Meidibao  commercial heat pump provides year-round comfort to any business or office. A heat pump split and monoblock system can take care of both your heating and cooling needs and save you money in the process.

A heat pump is an air conditioning condenser that is configured to work "in reverse"in the wintertime when heat is needed rather than cooling. You get a heater and air conditioner in one efficient unit. Our wide selection of air source heat pumps ensures that we have your heating and cooling needs covered, and our state-of-the-art products can save you an amazing amount of money on energy bills. Our inventory of heat pumps includes 220- and 420-volt units.
